Titanium Grade 5
Material Notes: Titanium Grade 5, or Ti Gr5, also known as Ti-6Al-4V, is an alloy that is predominantly made up of titanium (90% wt.), aluminum (6% wt.), and vanadium (4% wt%). Despite only consisting of 10 % additional elements, the alloy is desired in a multitude of industries due to its exceptional lightweight nature, strength, and corrosion and wear resistant qualities.
Applications: Titanium Grade 5 (TA6V4) is widely employed for parts of structures, for fasteners in the aerospace industry and marine applications owing to its extensive resistance to corrosion. Normally, it is treated by annealing, although, its heat treatment can enhance its temperature resistance up to 350 degrees Celsius.
Specifications for Titanium Grade 5
The table provides all relevant information with respect to properties like mechanical, chemical, and physical aspects of Titanium Grade 5 along with its strength, nominal composition and thermal performance features.
| Property Category | Attribute | Value |
|---|---|---|
| Mechanical Properties | Tensile Strength (Ultimate) | 950–1170 MPa (138,000–145,000 psi) |
| Tensile Strength (Yield) | 880–1100 MPa (128,000–160,000 psi) | |
| Elongation at Break | 10–14% | |
| Hardness | Brinell: 334, Rockwell C: 36 | |
| Chemical Composition | Titanium (Ti) | 87.725–91% (balance) |
| Aluminum (Al) | 5.5–6.75% | |
| Vanadium (V) | 3.5–4.5% | |
| Other Elements (e.g., Fe, O) | Fe ≤ 0.3%, O ≤ 0.2%, N ≤ 0.05%, H ≤ 0.015%, C ≤ 0.08% | |
| Physical Properties | Density | 4.43 g/cm³ (0.16 lb/in³) |
| Melting Point | 1604–1660°C (2919–3020°F) | |
| Thermal Conductivity | 6.7–7.2 W/m·K (46.5–50.0 BTU·in/hr·ft²·°F) |
View our latest news
The importance of plastic machining in industries that require precision-engineered components cannot be overemphasized; it is among the most versatile materials for such applications. Both plastics have similar features;...
The CNC milling machine is an advanced manufacturing method that offers unique accuracy, productivity, and flexibility in making complicated parts and elements. Nevertheless, what is a CNC mill? Furthermore,...
Modern manufacturing has been changed by CNC (Computer Numerical Control) machines that give unmatched efficiency, precision, and flexibility. Experts in the field or beginners in automated machining need to...
In the shaping and fabrication of metallic materials, there is a need to differentiate between metal cutting processes and machining processes for both industry professionals and amateurs. These two...
Get Titanium Grade 5 CNC machining parts from Hopeful
