304 Stainless Steel
Material Notes: The 304 grade of stainless steel is the basic ‘18/8 type’ of the family and it is well mastered for its scope of application and therefore available in a number of forms and finishes. It has superior welding properties thus making it a perfect choice for form or welding projects due to its balanced upper austenitic. 304 grade is widely used in various industrial, architectural, and transportation structures.
Applications: The products we manufacture and serve all have an application to stainless steel beer kegs, chemical equipment, dairy equipment, kitchen cooking tools, surgical implements used by hospitals, etc. Our dependable and adaptable materials guarantee optimal efficiency in kitchen sinks, pressure vessels, and more. Leverage us to deliver stainless steel products tailored to your requirements.
Specifications for Stainless Steel 304
| Property | Metric | English | Comments |
|---|---|---|---|
| Density | 8.00 g/cc | 0.289 lb/in³ | |
| Hardness, Brinell | 123 | 123 | Converted from Rockwell B hardness. |
| Hardness, Knoop | 138 | 138 | Converted from Rockwell B hardness. |
| Hardness, Rockwell B | 70 | 70 | |
| Hardness, Vickers | 129 | 129 | Converted from Rockwell B hardness. |
| Tensile Strength, Ultimate | 505 MPa | 73200 psi | |
| Tensile Strength, Yield | 215 MPa @ Strain 0.2% | 31200 psi @ Strain 0.2% | |
| Elongation at Break | 70% | 70% | in 50 mm |
| Modulus of Elasticity | 193 GPa | 28000 ksi | |
| Poisson's Ratio | 0.29 | 0.29 | |
| Shear Modulus | 77.0 GPa | 11200 ksi | |
| Izod Impact | 150 J @ -195 °C | 111 ft-lb @ -319 °F | V-Notch |
| 150 J @ 21.0 °C | 111 ft-lb @ 69.8 °F | V-Notch | |
| Charpy Impact | 325 J | 240 ft-lb | |
| Electrical Resistivity | 0.0000720 ohm-cm @ 20.0 °C | 0.0000720 ohm-cm @ 68.0 °F | |
| 0.000116 ohm-cm @ 650 °C | 0.000116 ohm-cm @ 1200 °F | ||
| Magnetic Permeability | 1.02 | 1.02 | at RT |
| CTE, linear | 17.3 µm/m-°C @ 0-100 °C | 9.61 µin/in-°F @ 32-212 °F | |
| 17.8 µm/m-°C @ 0-315 °C | 9.89 µin/in-°F @ 32-599 °F | ||
| 18.7 µm/m-°C @ 0-650 °C | 10.4 µin/in-°F @ 32-1200 °F | ||
| Specific Heat Capacity | 0.500 J/g-°C @ 0-100 °C | 0.120 BTU/lb-°F @ 32-212 °F | |
| Thermal Conductivity | 16.2 W/m-K @ 0-100 °C | 112 BTU-in/hr-ft²-°F @ 32-212 °F | |
| 21.5 W/m-K @ 500 °C | 149 BTU-in/hr-ft²-°F @ 932 °F | ||
| Melting Point | 1400 - 1455 °C | 2550 - 2651 °F | |
| Solidus | 1400 °C | 2550 °F | |
| Liquidus | 1455 °C | 2651 °F | |
| Carbon, C | <= 0.080% | <= 0.080% | |
| Chromium, Cr | 18 - 20% | 18 - 20% | |
| Iron, Fe | 66.345 - 74% | 66.345 - 74% | as balance |
| Manganese, Mn | <= 2.0% | <= 2.0% | |
| Nickel, Ni | 8.0 - 10.5% | 8.0 - 10.5% | |
| Phosphorus, P | <= 0.045% | <= 0.045% | |
| Silicon, Si | <= 1.0% | <= 1.0% | |
| Sulfur, S | <= 0.030% | <= 0.030% |
View our latest news
The importance of plastic machining in industries that require precision-engineered components cannot be overemphasized; it is among the most versatile materials for such applications. Both plastics have similar features;...
The CNC milling machine is an advanced manufacturing method that offers unique accuracy, productivity, and flexibility in making complicated parts and elements. Nevertheless, what is a CNC mill? Furthermore,...
Modern manufacturing has been changed by CNC (Computer Numerical Control) machines that give unmatched efficiency, precision, and flexibility. Experts in the field or beginners in automated machining need to...
In the shaping and fabrication of metallic materials, there is a need to differentiate between metal cutting processes and machining processes for both industry professionals and amateurs. These two...
Get 304 Stainless Steel CNC machining parts from Hopeful
